Hermetic, High Capacitance, High Endurance, High Reliability, High Shock & Vibration, High Ripple Current, Long Life, Low ESR, Low Leakage Current, MIL, Power Dense, Stability, Wide Temperature Operating Range
Applications:
Aerospace & Defense, Directed Energy & Pulsed Power, Radar & RF Transmit/Pulse Modules, Power Hold-Up & Uninterruptible Power, Electric Propulsion & Space Power, Electronic Warfare & Ruggedized Computing, Power Conversion & DC-Link Filtering, Harsh Environment, General Industrial Energy Storage
Voltage 75°C:
10
Voltage 85°C:
10
Voltage 125°C:
6
DCL @25°C (µA):
350
DCL @ 85 °C (µA):
≤0.01 CV or 3 μA
Tolerance:
±20% Std (±10% Optional)
Dielectric:
Ta₂O₅
ESR (mΩ):
15
Termination:
Sn63/Pb37
Mounting Type:
Thru-hole
Dimension (in/mm):
L 1.40 (35.6mm) x W 1.40 (35.6mm) x H 0.6" (15.24 mm)
